Size & Weight

MAIN UNIT SIZE (W X H X D) 430 x 54 x 306 mm

MAIN UNIT WEIGHT 2.7 kg

FRONT SPEAKER SIZE (W X H X D) 92x272x97 mm

FRONT SPEAKER WEIGHT 0.65 kg

CENTER SPEAKER SIZE (W X H X D) 241x92x85 mm

CENTER SPEAKER WEIGHT 0.6 kg

SURROUND SPEAKER SIZE (W X H X D) 91x203x92 mm

SURROUND SPEAKER WEIGHT 0.55 kg

SUBWOOFER SIZE (W X H X D) 230x365x360 mm

SUBWOOFER WEIGHT 6.3 kg

General Features

POWER OUTPUT 1000W

FORM FACTOR 5.1

BLUETOOTH YES

BRAVIA SYNC HDMI-CEC YES

1080P UPSCALER YES

HDMI AUDIO RETURN CHANNEL YES

S-MASTER DIGITAL AMPLIFIER 24bit

BAND (FM / AM) FM

PRESET STATION (FM / AM) 20 (FM)

AUTO SCAN TUNING YES

AV SYNC YES

SLEEP YES

SCREEN SAVER YES

AUTO POWER OFF (AUTO STAND-BY) YES

Video / Audio / Photo Playback

DVD YES

CD YES

USB FILE SYSTEM (FAT32, NTFS) Yes(FAT12/16/32)
VIDEO YES

MUSIC YES

PHOTO YES

Audio Decoding

LPCM (2CH / 5.1CH / 7.1CH) LPCM (2ch)

DOLBY® DIGITAL YES

Sound Mode

SOUND MODE AUTO YES

SOUND MODE MOVIE YES

Surround Setting

DOLBY PROLOGIC YES

Interface

INPUT AND OUTPUT TERMINALS

Analog Audio Input(1), Composite Video Output(1), HDMI Output(1), Optical Audio Input(1), USB Input(1)
